On Grid Solar System
| NO. | Item | Specification | QTY | Unit |
| 1 |
Poly PV modules (1) the installation way: the bracket and the clamp fixed installation （2）With junction box & 900mm solar cable |
JCN-P260-30(1640*990*35) | 20 | pcs |
| 2 |
Grid-tied inverter （1）Installation：wall-mounted type （2）Accessories：card、stainless steel bolt、stainless steel screws |
5000W (pure sine wave) | 1 | set |
| 3 |
AC distribution box （1）Installation：wall-mounted type （2）Sensor parts: current meter, voltage meter, current transformer （3）The other terminal, signal lamp, wire, miscellaneous |
Single phase 5kw(Wall-mounted & waterproof outdoor use) | 1 | set |
| 4 |
Photovoltaic cable (DC) (1)From solar PV module to inverter |
PV1-F 4mm - PV cable | 70 | m |
| 5 |
AC solar cable (1)From inverter to AC distribution box |
ZR-YJV 0.6/1kV 3*6mm2 | 12 | m |
| 6 | Male female connector | MC4 connector | 4 | pair |
| 7 |
PVC threading tube (1)Diameter 40mm PVC hard tube |
Internal diameter 40mm | 40 | m |
| 8 | PVC hard pipe elbow | Match with PVC hard wire tube | 13 | pcs |
| 9 | Insulating tape | 1 | volume | |
| 10 | Cable ties | 3*100mm | 1 | parcel |
